The Micro Motion 5700 transmitter delivers precise Coriolis flow measurement, featuring a user‑friendly display for meter status, characterization, and output configuration. The manual guides setup, calibration, and integration with Ethernet and Fieldbus systems. It supports updates now
Physical and Technical Overview
The Micro Motion 5700 transmitter is a compact, rugged unit designed for high‑accuracy Coriolis flow measurement. Its dimensions are 140 mm long, 90 mm wide, 70 mm high, and it weighs 4.5 kg, making it ideal for mounting on standard instrument panels or inline with piping systems. It operates on 24 VDC power!!
The unit features a 2‑inch color LCD protected by tempered glass, displaying real‑time mass flow, volume flow, temperature, and pressure. It has NEMA 4X 4‑wire connectors for fluid input and output, a 4‑wire power inlet, and a 4‑wire data port supporting FOUNDATION Fieldbus and Ethernet/IP.
The transmitter supports FOUNDATION Fieldbus (1‑M/2‑M) and Ethernet/IP. An integrated webserver, accessed via a local IP, provides a user interface for monitoring and configuration. Firmware can be updated over the network or from a USB flash drive, with all changes logged securely and diagnostics.!!!
The 5700 uses a dual‑sensor Coriolis design with ±0.1 % repeatability and <0.05 % linearity error. It measures 0.1 to 200 kg/h over –20 °C to +80 °C. Internally, temperature and pressure sensors keep accuracy. Outputs can be 4–20 mA, 0–10 V, 0–5 V, or digital via Fieldbus and diagnostics.!!!
Safety compliance is built into the 5700, meeting IEC 61508 and IEC 61511. It offers over‑temperature protection, pressure relief, and a safety relay that can trigger external SIS messages. Firmware logs all safety events, ensuring traceability and audit readiness for critical process control.
Installation Procedures
Begin by selecting a level mounting surface within the instrument panel. Position the Micro Motion 5700 transmitter so that inlet and outlet ports face the fluid flow direction. Secure the unit with the supplied mounting brackets, tightening screws to the manufacturer’s torque specifications.
Connect the 24 VDC power supply to the power inlet, observing correct polarity. Use a dedicated power cable rated for the operating environment and route it away from high‑temperature or high‑vibration zones. Ground the transmitter chassis to the facility grounding system through the grounding terminal to prevent electrostatic buildup.
Attach the fluid inlet and outlet fittings to the transmitter’s NEMA 4X connectors. Verify compatibility with the process fluid’s pressure rating and temperature range. Tighten all fittings to the specified torque to avoid leaks. Install pressure relief valves upstream and downstream as required by process safety standards.
For data communication, connect the Ethernet/IP or FOUNDATION Fieldbus cable to the data port. If using Ethernet, configure the IP address via the webserver or a temporary console connection. Ensure the network switch supports the required bandwidth and that the transmitter’s MAC address is registered in the network management system.
After all connections are made, power on the transmitter. The display will show a self‑test sequence; verify that all status indicators read normal and that the display shows a green status light. If any error codes appear, consult the diagnostic section of the manual. Once the unit passes the self‑test, proceed to the initial calibration in the next section.
Apply a pressure of 1.5 bar above normal operating pressure to test for leaks. If the test is successful, the transmitter is ready for commissioning! All steps must be performed by qualified personnel.
Calibration and Characterization
Use the transmitter display to check meter status. Follow the step‑by‑step meter characterization sequence, recording mass and volume flow values. Configure output parameters, then save settings. Verify accuracy with a reference and vol standard.
Meter Status Check
Before any calibration or operation, the user must verify the meter’s health and readiness. The Micro Motion 5700 transmitter offers a dedicated “Meter Status” screen accessible from the main menu. This screen displays a concise list of diagnostic flags, each accompanied by a numeric code and a brief description. The status screen is refreshed automatically every 10 seconds, ensuring that any transient faults are captured promptly.
Key indicators include:
- Temperature: Shows the internal sensor reading in °C. Values outside the range 0 °C–80 °C trigger a warning.
- Pressure: Displays the inlet pressure in bar. A pressure below 1 bar or above 10 bar sets a fault flag.
- Signal Integrity: Indicates the quality of the Coriolis signal. A low signal‑to‑noise ratio (SNR) below 30 dB is flagged.
- Communication: Reports Ethernet and FOUNDATION Fieldbus link status. A disconnected link shows as “Link Down.”
- Calibration: Shows the last calibration date and the number of calibration cycles performed. If the cycle count exceeds the manufacturer’s recommendation, a maintenance alert appears.
To interpret the status, the operator should cross‑reference the numeric codes with the troubleshooting section of the manual. For example, code 0x01 indicates a “Temperature out of range” condition, while 0x0A denotes a “Signal integrity loss.” The display also offers a “Clear” button that resets all temporary fault flags after the underlying issue has been resolved.
In addition to the visual display, the transmitter can export status data via the integrated webserver. By navigating to the “Operations” tab and selecting “Export Status,” the user can download a CSV file containing timestamped readings for each diagnostic parameter. This feature is invaluable for trend analysis and preventive maintenance planning.
Regular meter status checks are essential for ensuring measurement accuracy, preventing data loss, and extending the transmitter’s service life. Operators should perform these checks at the start of each shift and whenever a significant change in process conditions is detected.
Meter Characterization Steps
The Micro Motion 5700 transmitter requires a systematic characterization to ensure accurate Coriolis flow measurement; Select “Characterize” from the main menu, enter expected flow range, fluid density, and temperature. The transmitter then initiates calibration pulses automatically. The display shows progress and fault flags. The user can review data before proceeding. Quickly. Now.
During the cycle, the transmitter records mass flow, volume flow, and temperature at several points. The user can pause to verify readings or adjust the flow range. After the cycle, correction coefficients are calculated and applied to the flow algorithm. The transmitter logs each measurement point to internal memory for post‑run analysis. The exported data can be reviewed on a PC.
To verify accuracy, run a “Check” command that compares the transmitter’s output to a reference standard. A deviation below 0.5 % is acceptable. If the deviation exceeds the threshold, repeat the characterization or adjust parameters. Once the check passes, select “Save” to store the new coefficients permanently. The webserver can export calibration data for archival. The exported data can be reviewed on a PC.
It is recommended to perform a full characterization at least once every 12 months or after major maintenance. The manual also covers troubleshooting for signal drift, temperature instability, and communication errors. Regular calibration ensures compliance with industry standards. It supports ISO 9001.
Output Configuration
The 5700 transmitter offers flexible output options for mass flow, volume flow, temperature, and pressure. Access the Output menu from the main screen. Select the desired output type and configure the scaling factor to match the receiving device. The transmitter supports analog 4‑20 mA, 0‑10 V, and digital protocols such as FOUNDATION Fieldbus and Ethernet/IP. For analog outputs, set the Zero and Span values to align with the instrument’s range. Digital outputs require specifying the destination address and data format. The webserver provides a real‑time view of each output channel; the Operations tab displays totalizers and inventory counters After setting the parameters, press Save to commit the configuration. The transmitter will automatically update the output during operation. To verify the output, use the Output Test function, which displays the current output value on the screen. If the value deviates from the expected range, adjust the scaling or check the wiring. The transmitter logs all output changes for audit purposes. Regularly review the log to detect drift or communication faults. The manual recommends performing an output check after each calibration cycle. By configuring outputs correctly, the 5700 ensures accurate data transmission to control systems and data historians. The configuration process is documented in the user manual and can be replicated via the integrated webserver for remote management. This flexibility allows operators to adjust scaling
Integration with Ethernet and Webserver
The 5700 transmitter’s Ethernet port supports TCP/IP, Modbus/TCP, and HTTP. Use the web interface to view flow, set parameters, and monitor totalizers. Firmware updates are delivered via the webserver. Webserver hosts diagnostics andlogs.
Webserver Operations Tab
The Operations tab displays real‑time mass flow, volume flow, temperature, and pressure in metric or imperial units. A live graph updates every second, and status indicators show transmitter health, battery voltage, link status, and error flags. Alarms are highlighted in red, and totalizers display cumulative mass and volume over the life of the meter. Inventory data can be viewed to verify calibration history. The dashboard also lists alarms and allows quick reset or save of settings. The transmitter supports dual output modes, routing analog and digital signals to PLCs or SCADA for flexible integration and real-time monitoring!?
The Firmware Update process includes a checksum verification step. Alarms are highlighted, and display mass and volume. The Totalizer view shows cumulative mass and volume totals, with reset the counters and
All interactions are secured via HTTPS. User authentication is required to access the Operations tab. The web server logs each session, providing an audit trail for compliance and security reviews. The responsive design ensures the interface remains usable on tablets and smartphones, enabling field technicians to monitor from the shop floor or on the move. The interface adapts to different screen sizes, providing a consistent experience. Users can set email alerts for critical events, and the system supports remote firmware updates also over the network.
Webserver Configuration Tab
The Configuration tab allows full control over the transmitter’s network, security, and output settings. Users can set the IP address, subnet mask, gateway, and DNS servers, or enable DHCP for automatic assignment. The Network section also supports VLAN tagging and port mirroring for advanced traffic management. Under Security, administrators can configure HTTPS certificates, set user roles, and enable two‑factor authentication to protect against unauthorized access. The Output panel defines analog voltage and current ranges, digital pulse rates, and the mapping of mass and volume data to each channel. Calibration constants and scaling factors are editable here, ensuring the transmitter reports accurate values to the host system. The Logging feature records all configuration changes, providing an audit trail for troubleshooting and compliance. Users can schedule firmware upgrades, set update windows, and monitor progress directly from the web interface. The tab also offers a Diagnostics tool that runs self‑tests, displays error codes, and recommends corrective actions. Finally, the Backup function creates a downloadable copy of the current configuration, allowing quick restoration after a reset or hardware replacement. All changes are applied in real time, and the interface validates inputs before saving to prevent misconfiguration.
Advanced options allow selection of Modbus, OPC UA, or BACnet, adjustment of sampling rate, and setting programmable alarm thresholds for flow, pressure, and temperature. All changes persist across power cycles.
Setup is intuitive and fast!!!
FOUNDATION Fieldbus Configuration
The Micro Motion 5700 transmitter offers comprehensive FOUNDATION Fieldbus support, enabling direct integration with control systems. Access the web interface and select the Fieldbus tab to configure. Assign a unique Node ID within the network address space; this ID must be distinct from all other devices. Set the Baud Rate (19200 or 38400 bps) and match Data Bits, Parity, and Stop Bits to the master’s settings for reliable communication.
Configure the Data Objects that the transmitter will publish. The 5700 provides Process Data Objects (PDOs) for mass flow, volume flow, temperature, and pressure. Each PDO can be enabled, assigned a Data Type (e.g., 32‑bit float), and a Unit (kg/s, m³/h, °C, bar). Set the Sampling Interval to control update frequency. For safety‑critical applications, enable Fault‑Tolerant mode to switch to a redundant bus on fault detection.
Enable Control Objects to receive setpoints or start/stop commands from the master. Define the Control Data Type and Unit for each command, and map the action to the transmitter’s internal routine. This allows remote start/stop and setpoint adjustments.
Run a Fieldbus Diagnostics test to verify link status, error counts, and latency. If errors occur, check cable integrity, termination, and ensure the master’s address table includes the transmitter’s Node ID. After successful diagnostics, save the configuration to non‑volatile memory so it persists across power cycles.
Advanced users can adjust Transmission Window, Priority Levels, and Message Retransmission parameters in the Advanced Settings panel. Match these settings to the master’s configuration to meet timing constraints and ensure optimal performance.
All settings are saved to non‑volatile memory and persist after power cycles.
Safety and Compliance
Micro Motion 5700 meets IEC 61508 and IEC 61511 safety standards, providing built‑in SIS messages for fault detection. It supports UL 508A, CSA C22.2, and ISO 9001 certification, ensuring reliable, compliant operation in critical process environments. All logs comply with ISO 50001 audit!
Safety Instrumented Systems (SIS) Messages
Operators should review the SIS message history to detect patterns indicating sensor drift or component failure. The transmitter’s diagnostics support self‑test routines that can be triggered remotely, providing feedback on safety logic. See manual!!. Check manual for details.!!! OK!
Troubleshooting Guide
Check the transmitter’s error log for codes 0x01–0x0F, indicating sensor misalignment. Verify power supply voltage, inspect wiring for corrosion, and run the self‑test via the web interface. Refer to the manual’s troubleshooting section for detailed steps.
Common Issues and Resolutions
Typical problems with the 5700 transmitter include erratic readings, power instability, Ethernet timeouts, Fieldbus errors, and temperature warnings. The table below lists root causes and quick fixes.
- Erratic Flow Readings
Root cause: misalignment or vibration.
Fix: realign sensor, dampen vibration, rerun calibration. - Power Instability
Root cause: voltage droop or bad grounding.
Fix: check 24 V input, secure grounds, replace module if needed. - Ethernet Timeout
Root cause: network misconfig or bad cable.
Fix: verify IP settings, replace cable, test loopback. - Fieldbus Error
Root cause: wrong node ID or firmware mismatch.
Fix: set unique node ID, update firmware, rescan network. - High Temperature
Root cause: ambient >85 °C or poor cooling.
Fix: relocate unit, add fans, monitor temp via web.
Persistent issues should be logged through the webserver’s Diagnostics tab and reviewed against Appendix C. Contact Emerson support with serial number and logs for assistance.
Before contacting support, ensure the firmware is current, the transmitter’s internal clock is synchronized, and the temperature sensor is clean. Use the on‑screen diagnostics to capture error codes, then attach the log file to your support ticket.
All actions are logged automatically;
Maintenance and Firmware Updates
Routine care keeps the 5700 transmitter reliable. Inspect the housing for cracks, ensure seals remain intact, and verify that the mounting flange is torque‑tight to the manufacturer’s specification. Clean the sensor ports with a lint‑free cloth and a 70 % isopropyl alcohol solution; avoid abrasive materials that could damage the Coriolis tube.
Firmware should be refreshed at least once a year or whenever Emerson releases a patch. Use the integrated webserver: navigate to the Configuration tab, select Firmware Update, and upload the .bin file from the official site. The transmitter will reboot automatically; verify the version in the System section.
Before updating, back up the current configuration via the Export option. If the update fails, restore the backup and retry. Maintain a change log in the facility’s maintenance records, noting the date, firmware version, and any anomalies observed post‑upgrade.
Periodic calibration checks should follow the manufacturer’s schedule: perform a full characterization after every firmware change and after any significant environmental shift. Use the on‑screen Characterization wizard to capture new data, then save and verify the output against a reference standard.
If the transmitter displays a COMMUNICATION ERROR, check cable length and quality, then reset network settings. The 5700’s watchdog timer will automatically reset to a safe state if the timer expires, protecting against software crashes and ensuring continuous operation.
